Edwards D386-54-000 AGC 1-Display Standard Expansion Gauge Controller, 122282

The Edwards D386-54-000 AGC 1-Display Standard Expansion Gauge Controller (SKU 122282) is a precision instrument designed for controlling and displaying readings from vacuum gauges in industrial and laboratory environments. This single-display controller offers standard expansion capability, allowing users to scale their vacuum measurement system according to specific operational requirements. As part of Edwards' Active Gauge Controller (AGC) series, this unit provides reliable monitoring and control for a wide range of vacuum processes.

Overview

In vacuum system operations, accurate pressure measurement and control are critical for process consistency and equipment protection. The Edwards D386-54-000 gauge controller addresses these needs by serving as the central interface between vacuum gauges and system operators. It is intended for use in semiconductor manufacturing, thin-film deposition, leak detection, freeze drying, and other applications where precise vacuum levels are required. The standard expansion port enables future addition of display modules or channels, making it a flexible choice for both new installations and system upgrades. Its single-display configuration reduces complexity while providing essential pressure feedback.

Key Features

• 1-Display Interface: Provides a clear digital readout of vacuum pressure from a connected gauge, allowing operators to monitor conditions at a glance.
• Standard Expansion Capability: The controller includes an expansion interface that supports the addition of extra display modules or control units, offering scalability for evolving vacuum systems.
• Active Gauge Control (AGC): Integrated control logic manages gauge operation and signal processing, ensuring stable and accurate readings under varying process conditions.
• Compatibility with Edwards Vacuum Gauges: Engineered to work with Edwards gauge families, providing reliable integration and consistent performance across multiple gauge types.
• Rugged Design for Industrial Environments: Built to withstand the demands of continuous operation in manufacturing floors, research labs, and process facilities.

Technical Specifications

• Brand: Edwards
• Model: D386-54-000
• SKU: 122282
• Product Type: AGC 1-Display Standard Expansion Gauge Controller
• Display: Single (1-Display)
• Expansion: Standard (expansion-ready)

Applications

• Semiconductor Fabrication: Used to monitor and control vacuum levels in sputter coaters, etch chambers, and load locks within semiconductor manufacturing lines.
• Thin-Film Deposition: Provides pressure feedback for thermal evaporation, chemical vapor deposition, and physical vapor deposition systems.
• Leak Testing: Integrated into helium leak detectors or differential pressure leak test stations to ensure seal integrity.
• Freeze Drying: Controls chamber vacuum during lyophilization processes in pharmaceutical and food industries.
• Vacuum Furnace Operation: Monitors pressure in heat treatment, brazing, and sintering furnaces where consistent vacuum quality is required.

FAQ

• What is the purpose of the Edwards D386-54-000 gauge controller? It is used to control and display readings from Edwards vacuum gauges in industrial and laboratory vacuum systems, enabling operators to maintain precise pressure levels.
• How does the Standard Expansion feature work? The controller includes a dedicated expansion interface that allows users to connect additional display modules or control channels, making it possible to expand the system’s monitoring capabilities as needs grow.
• Is this controller suitable for use in semiconductor manufacturing? Yes, it is commonly employed in semiconductor processes that require accurate vacuum pressure control, such as sputtering and etching.
• What type of display does the controller have? It features a single digital display that provides clear pressure readout, designed for easy readability in both bright and dim environments.
